200~400MHz, Gain60dB, Noise Temp.43K, P-1dB8dBm, N
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
Low noise, high gain.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 200 | ~ | 400 | MHz |
| Gain | 60 | dB | ||
| Gain flatness | 0.4 | dB | ||
| Noise Temp. | 43 | K | ||
| VSWR | 1.4 | |||
| Gain slope | ±0.1dB | /10MHz | ||
| Gain slope | ±0.2dB | /40MHz | ||
| Gain stability | ±0.1dB | /hour | ||
| Gain stability | ±0.2dB | /day | ||
| Linear group delay | ±0.01ns | /MHz | ||
| Parabolic group delay | ±0.001ns | /(MHz)2 | ||
| Group delay ripple | ±0.1ns | /p-p | ||
| Maxi input level | 0 | dBm | ||
| IM3 | -40dBc | When outputting at -10dBm | ||
| P-1dB | 8 | dBm |
| Connector | N -JK |
| Connector material | Stainless steel |
| Impedance | 50Ω |
| Surface | Grey |
| Working voltage | +12-18V； SMA-K interface power supply |
| Working current | 300mA |
| Operation Temp. | -45~+55℃ Design assurance |
| Storage Temp. | -55~+70℃ Design assurance |
Store in an environment with a humidity of less than 25% and pay attention to dust and static electricity prevention.
